Steel Frame Roll Forming Machine

Multi-size door Frame making Machine

Wuxi LOTOS Manufacturing is one of professional ▷ Door Frame Making Machine | Making a door frame ◁ . also, If you have yourself door design, show us your design drawing, the good suggestion can be given out by our engineer. if you have any idea about your new project, some professional idea can be to get from us.

Door & Window Framing machines can be customized as per customer requirement based that Mostly known for its stability and superiority. LOTOSFORMING can be availed at the best competitive rates. A hollow Steel Door Frames can be used for both interior and exterior applications and these doors suitable for Commercial Metal Door Frames.



Door Frame Manufacturers

Fire Rated Door Frame machine

These Fire Rated door frame forming machine can be changed as per customer want basing. We believe in offering the best quality to our clients with timely deliveries at the most competitive value.

Steel Door frames enable support and flexibility to the door. Different types of doors like sliding doors and glass doors and wooden doors can be made stronger with metal door fact, LOTOS  has high stability and advantage.hence, Our Machines can be availed at the best competitive price.

The punching also can be designed according to your requirement. for instance, after roll formed by Roll Forming Machine, the surface will be very smooth and pretty without any scrape on a surface. this Machine equipment consists of De-coiler and feed and leveling device and punching machine with holes punching molds and main roll forming machine and cutter and run-out table, etc.


door frame machine

Multi Size Door Frame Roll Forming Machine

Heavy Duty is specially designed to produce steel metal window or steel multi size door frame that are solid and stable.

steel forming machine is suitable to form galvanized and CS Stainless steel and copper and so on. Mostly customer place order for galvanized steel door frame machine and for resident and business construction area usage steel door frame is more popular.

Door frame manufacturing machines are able to form a multi-width profile base on a country standard from 120-250 MM door frame width. Steel frame machine drives by gearbox and electronic motor to make sure your thick hard material can form standard.

And roller installs on 80 mm diameter shaft for long time usage by various forming speed. steel Door Frames are custom make to your characteristics to suit various types of wall construction and door sizes.

There are no limitations to produce types of door frame roll forming machine.LOTOS can prepare all kind of this machine for door frame profile such as:

  • Square Bend Door Frame
  • Standard Deluxe Door Frame
  • Robe Door Frame
  • Metro Door Frame
  • Shadow Line Door Frame
  • Dry Wall Door Frame
  • Flush Finish Door Frame
  • Split Door Frame
  • Double Rebate Door Frame
  • Single Rebate Door Frame
  • Double Rebate Mullion/Transom Door Frame
  • Single Rebate Mullion/Transom Door Frame
steel door-frame-machine

Steel Door Frame Machinery


  • Material: Galvanized Coil
  • Material Thickness: 1.2-2.5 mm
  • Main roll forming machine Power: 15 KW
  • Forming Speed: 5-10m/min
  • Dimension: 14×0.8×0.9 m (L*W*H)
  • Weight: 8-10 T

2)Main Parts

  • Manual 3T un coiler
  • Feeding Guide
  • Roll Forming System
  • Hydraulic Cutting
  • Control system
  • Output table

3)Working Flowing

Manual Un coiler    —>       Feeding     —>        Roll Forming   —>        Cutting —>    Output table

4)Technical Data of Custom Design

  • Un coiler
Un coiler TypeManual
Loading capacity5 Ton

Impassive to expanding

  • Roll Forming system with the feed panel unit
Axis Diameter65 mm
Forming Roller station20 Groups
Main Axis materialFirst-grade 45# steel

heated and quenched

Roller materialFirst grade 45# steel,

Hard Chrome Coated,

heated and quenched

Forming Speed5-10 m/min
Drive Type1.5” Chain of transmission
Chain sizeJapan CHOHO 120#
Machine Frame standWelded structural steel,

thickness 14mm

  • Hydraulic Cutting Device
Cutting typeHydraulic stop cutting
Hydraulic pressure12 Mpa

Blade & cutter


Cr12, quenching process 58-62
Cutting length tolerance10m±2mm
  • Electrical System
Length ControllerEncoder Japan KOYO
OperationTouch Screen
InverterJapan YASKAWA
iron door-frame
steel-forming machine
door-frame-machine price

Door Frame Bending Machine

Now days so many manufacturers around the world still making door frame with door frame bending machine for such believing that can bend different thickness of the sheet and produce various width door frame with the bending machine.

In fact, LOTOSFORMING working completely automatic with PLC control, even punching and stamping for lock whole and hinge position working automatically by PLC control for left hand and right hands doors.

To set the punching whole position on iron door frame we have 2 different pages on roll forming machine PLC program to convenient and user-friendly manufacturing. But LOTOSFORMING as an experienced manufacturer in china design and manufacture multi size door frame roll forming machine for 0.9 – 2.5 MM different steel.

Steel door frame manufacturing process takes 4 months from roll forming design to machining and heat treatment welding structure surface machining for the door frame. So Door frame machine price starts from 20 K USD to 80k fact, it’s all about door frame machine quality and level of steel door frame manufactures.

LOTOSFORMING has already manufactured and installs more than 180 complete lines around the world successfully. For getting more knowledge about this machine watch video by this link:

steel door machine

In the construction field, one of the most important parts of the building is the doors. each apartment should well be furnished by the safe and strong main door, for safety and view. so many manufacturers are working on door production to support most safe and beautiful doors. some of the main standards of the acceptable door are:

1: main cross door for each apartment should have a safety lock from inside that can make sure no matter what it won’t open by thieving from outside. The old design doors were just with a simple middle lock, that easily can break but now most of the doors are with side and top lock that not easily can break.

2: the standard door should be well joint with a frame that absorbed sound and dust and so on from out to in.

3: as we all know one of the safest spots in earth-quick is standing indoor frame.
So the door frame should be strong and stable.

Door frame producing process:
Up to wall thickness and country standard people using different door frame, but the latest standard and safe way of producing door frame are ROLL FORMING LINE.
By roll forming line can produce door frame continuously and align.

Advantages using of door frame roll forming line are:
1: with one set of door frame forming machine can produce any type of frame with different width and height.
2: Hing and lock spot will be easily punched during forming on the frame.
3: with roll forming machine can form several different thicknesses of steel and up to the usage of doors can make heavier or lighter doors.
So in the last generation of doors production, we highly recommended manufacture to use a roll forming line to satisfy market demand.
