light gauge steel framing machine

  1. Home
  2. light gauge steel framing machine

CAD/CAM Roll forming Machine

LOTOS design CAD/CAM Roll forming machine for the target of producing Light Steel Framing. Each part is dimpled and notched with the holes ready to accept fasteners so that components self-clip together with no clamping. This design enables to snap the parts together, add the fasteners and have a completed frame. We design CAD/CAM Roll forming machine for the purpose of producing light steel framing.

Light Steel Framing Machine

light gauge steel framing for building application. LOTOSFORMING is a steel stud manufacturing of steel stud roll forming machine. We produce steel framing machine that is suited for any type of projects. Our metal stud machines for sale are well suited for any type of construction project. building with a Light Steel Framing is an innovative solution with numerous applications. projects. ADVANTAGES OF LIGHT GAUGE STEEL CONSTRUCTION:
  • Their higher strength allows greater spacing between members when compared to wood frame construction.
  • It is easy to change or modify this construction at any point in its lifespan.
  • There is a great range of systems and products catering to this type of construction.
  • Light gauge steel structures are non-combustible, which is a code requirement for some types of structures.
  • Light gauge steel structures do not rot, shrink, warp, or decompose like wood structures, and can be used in areas where there is a probability of termite attack.
LOTOS Building Light gauge steel framing roll forming machine, fully automatic, hydraulic system, with the tolerance of punching is ±0.5mm.A process on roll forming line for screw hole, chamfer, web through a hole, small side shear, pipeline hole, web necking, shear, web foundation hole, etc.

Light Keel Villa Forming Machine

  • Summary
Material: Galvanized Coil Material Thickness: 0.5-0.9mm Main roll forming machine Power: 5.5KW Forming Speed: 25-30m/min Dimension: 6×0.7×0.8 m (L*W*H)
  • Main Parts
  1. Manual uncoiler
  2. Feeding Guide
  3. Roll Forming System
  4. Hydraulic Cutting
  5. Control system
  6. Output table
  • Working Flowing
Manual Uncoiler —>Feeding —> Roll Forming —> Cutting —>  Output table

Light Gauge Steel Framing Machine:

  • Profile and punches:
    Sheet     89mm×41mm C profile Light-Gauge-Steel-Framing-Machine
Additional Triad hole for wall and ground (two holes dia 3.5mm for wall  and one hole dia 16mm for ground)
  • Main components:
Item Description Quantity
1 Decoiler 1 Nos
2 Main roll forming machine with punching and cutting units 1 Nos
3 Controller 1 Nos
4 Out-put table 1 Nos
5 Spares and tools 1 Nos
  • Machine details:
No. Description Specification
1 Performance Transmission type Servo motor + chain
Hydraulic station motor power Approx 5.5kW
Productivity Approx 33m/min
Accuracy ±1mm
2 Main machine Roll former station Approx 14stations
Roller material GCr15 bearing steel chromed
Side plate Aluminum alloy with anode treatment
Spindle material 40Cr thermal refining
3 Punching Before forming Hydraulic cylinder pre-punching
Punch material Cr12MoV
Mould quality 6Nos
4 Cutting After forming Hydraulic cylinder profile-cutting
Blade material Cr12MoV
Mould quality 1Nos
5 Control Production Windows 8
Commissioning Wireless remote
6 Decoiler Automatic decoiler Electrical expansion
Loading capacity Max. 3tons
Internal diameter of coil 430mm-590mm
Outer diameter of coil Max. 1300mm
Width of coil Max. 450mm
Thickness of coil 0.75-1.2mm
Raw material of coil G550
