Product description
ERW Tube Mill Line (19-76mm)
|
Produce capacity: |
|
No. |
Item |
Working range |
Remark |
|
1 |
O.D of round pipe |
Φ19mm~Φ76mm |
|
|
2 |
Round pipe thickness |
0.7mm~3.0mm |
|
|
3 |
Square tube size |
20×20mm~60×60mm |
|
|
4 |
Square tube thickness |
0.7mm~2.5mm |
|
|
5 |
Rectangular tube size |
20×30mm~50×70mm |
|
|
6 |
Rectangular tube thickness |
0.7mm~2.5mm |
|
|
7 |
Produce speed |
Max 120M/min |
|
|
8 |
Pipe Length |
6-12M |
|
|
Steel strips specification: |
|
No. |
Item |
Working range |
Remark |
|
1 |
Thickness of strips |
0.7mm~3.0mm |
Material: Cold-rolled steel Hot-rolled steel |
|
2 |
Width of strips |
80mm~320mm |
|
|
3 |
O.D. of steel coil |
Φ800mm~Φ1600mm |
|
|
4 |
I.D. of steel coil |
Φ450mm~Φ550mm |
|
|
5 |
Maxi. load weight |
≤3000kgs |
|
Working flow: |
Raw material (steel coil) → uncoiling → shearing and butt-welding → material accumulating → non-power leveling →mill-forming → high-frequency welding(solid state) → removing burrs outside of weld seam → cooling → sizing → Turkish head → cold saw cutting → run-out table
